Commonly used in small electronic devices that has limited installation foot print. Pig-tail design for dip insert on PCB for reflow solder manufacturing process.

• UL, CSA, VDE (see specification for details)
• EU RoHS, REACH

Model Number	Rated Current	Rated Voltage	Blow Type	Casing Material	Certification
MFH	50mA~15A	125V	Fast Acting	Ceramic	UL/CSA
MFH-P	50mA~15A	125V	Fast Acting	Ceramic + Lead Wire	UL/CSA
MFH-PA	50mA~15A	125V	Fast Acting	Ceramic + Pig-Tail	UL/CSA
MFG36	0.1A~30A	125V	Fast Acting	Glass
MFG36-PA	0.1A~30A	125V	Fast Acting	Glass + Pig-Tail
PTS	100mA~5A	250V	Slow Blow	Ceramic	UL/CSA
PTP	100mA~5A	250V	Slow Blow	Ceramic + Pig-Tail	UL/CSA
PBS	0.1A~8A	250V	Fast Acting	Ceramic	UL/CSA
PBP	0.1A~8A	250V	Fast Acting	Ceramic + Pig-Tail	UL/CSA
PBS	0.1A~8A	250V	Fast Acting	Ceramic	UL/CSA
PBP	0.1A~8A	250V	Fast Acting	Ceramic + Pig-Tail	UL/CSA
PDS	0.1A~10A	250V	Slow Blow	Glass	UL/CSA
PDP	0.1A~10A	250V	Slow Blow	Blass + Pig-Tail	UL/CSA
PGS	0.1A~10A	250V	Fast Acting	Glass	UL/CSA
PGP	0.1A~10A	250V	Fast Acting	Glass + Pig-Tail	UL/CSA
PTU	250mA~6.3A	250V	Slow Blow	Ceramic + Pig-Tail	UR/CSA/VDE
PBU	50mA~6.3A	250V	Fast Acting	Ceramic + Pig-Tail	UR/CSA/VDE

* Please contact our sales for detail specification.
* Standard Package: 1,000 PCS per polybag.
