AFF Female Type Cartridge Fuse is the original type fuse link used in power distribution in car fuse boxes. Transparent top cover for easy diagnostic.
![](images/icon02.gif)
![](images/icon02.gif)
- ISO 8820-4
- EU RoHS, REACH
![](images/icon02.gif)
% of Rating | Current Rating | Opening Time | |
Minimum | Maximum | ||
110% |
20 – 60 Amp |
100 hrs | - |
135% | 20 – 60 Amp | 60 Sec |
1800 Sec |
200% |
20 – 60 Amp | 2 Sec |
60 Sec |
350% | 20 – 60 Amp | 0.2 Sec |
7 Sec |
600% |
20 – 60 Amp | 0.04 Sec |
1 Sec |
![](images/icon02.gif)
Catalogue Number | Amperage Rating | Voltage Rating | Color Code |
AFX-20 | 20A | 32VDC | LT. BLUE |
AFX-30 | 30A | 32VDC | PINK |
AFX-40 | 40A | 32VDC | GREEN |
AFX-50 | 50A | 32VDC | RED |
AFX-60 | 60A | 32VDC | YELLOW |
![](images/icon02.gif)
Export Packaging: 500PCS/polybag, 5000PCS/carton.
